Synthesis of Y6-xCa1.5xSi11N20O:Ce3+ (x = 0 ~ 2.5) Oxynitride Phosphor with Broad Emission Wavelength for 1pc-LED

Joonseo Park; Jin-Woong Lee

doi:10.3740/MRSK.2021.31.4.188

All Issue

2021 Vol.31, Issue 4 Preview Page Next Page

Synthesis of Y_6-xCa_1.5xSi₁₁N₂₀O:Ce³⁺ (x = 0 ~ 2.5) Oxynitride Phosphor with Broad Emission Wavelength for 1pc-LED

April 2021. pp. 188-194

PDF XML

Abstract

A Y_6-xCa_1.5xSi₁₁N₂₀O:Ce³⁺(x=2.5) oxynitride phosphor is synthesized at 1,750 °C in a mixed gas atmosphere of 5% H₂ and 95 % N₂ by using YN, Ca₃N₂, Si₃N₄, and CeO₂ as raw material reagents. The crystal structure is a trigonal crystal system that has a _P31_c (no.159) space group and has lattice parameters of a, b = 9.8876(3), and c = 10.6806(4). This structure is an Er₆Si₁₁N₂₀O structure type in which a Y_6-xCa_1.5xSi₁₁N₂₀O structure is formed by substituting a trivalent Y³⁺ element and a bivalent Ca²⁺ element at the position of Er element having an oxidation number of +3. Here, the charge difference caused by different oxidation numbers is balanced by the occupancy of a partially vacant 2c site and an O/N anion ratio in the Er₆Si₁₁N₂₀O structure type. The Y_6-xCa_1.5xSi₁₁N₂₀O:Ce³⁺ (x = 2.5) phosphor is yellow powder with yellow luminescence; performing Rietveld refinement on the phosphor on the basis of the data obtained by XRD measurement results in the lattice parameters as described above. The Y_6-xCa_1.5xSi₁₁N₂₀O:Ce³⁺ (x = 2.5) phosphor has a broad emission band due to Ce³⁺ as an activator with the center wavelength of 565 nm. This phosphor has a broader emission band than a YAG:Ce³⁺ phosphor, which is a representative LED phosphor, and thus extends further into the blue and red spectrum ranges. Accordingly, this phosphor is an interesting phosphor that can be used for 1pc-LED with an improved color rendering index.

Keywords

oxynitride phosphor

rietveld refinement

density functional theory

color rendering index

References

K. M. Kinsman, J. McKittrick, E. Sluzky and K. Hesse, J. Am. Ceram. Soc., 77, 2866 (1994). 10.1111/j.1151-2916.1994.tb04516.x

N. Hirosaki, R.-J. Xie, K. Kimoto, T. Sekiguchi, Y. Yamamoto, T. Suehiro and M. Mitomo, Appl. Phys. Lett., 86, 211905 (2005). 10.1063/1.1935027

K. Uheda, N. Hirosaki, Y. Yamamoto, A. Naito, T. Nakajima and H. Yamamoto, Electrochem. Solid State Lett., 9, H22 (2006). 10.1149/1.2173192

J. E. Murphy, F. Garcia-Santamaria, A. A. Setlur and S. Sista, SID Symp. Dig. Tech. Pap., 46, 927 (2015). 10.1002/sdtp.10406

M. Kim, W. B. Park, B. Bang, C. H. Kim and K.-S. Sohn, J. Mater. Chem. C, 3, 5484 (2015). 10.1039/C5TC00757G

M. Kim, S. P. Singh, S. Shim, W. B. Park and K.-S. Sohn, Chem. Mater., 32, 6697 (2020). 10.1021/acs.chemmater.0c02243

S. Jang, J. K. Park, M. Kim, K.-S. Sohn, C. H. Kim and H. Chang, RSC Adv., 9, 39589 (2019). 10.1039/C9RA05929F

J. H. Lee, S. P. Singh, M. Kim, M. Pyo, W. B. Park and K.-S. Sohn, Inorg. Chem. Front., 6, 3493 (2019). 10.1039/C9QI01002E

S. P. Singh, M. Kim, W. B. Park, J.- W. Lee and K.-S. Sohn, Inorg. Chem. Front., 55, 10310 (2016). 10.1021/acs.inorgchem.6b0157627676461

10.

W. B. Park, S. P. Singh, M. Kim and K.-S. Sohn, Inorg. Chem., 54, 1829 (2015). 10.1021/ic502721h25594669

11.

W. B. Park, S. P. Sing and K.-S. Sohn, J. Am. Chem. Soc., 136, 2363 (2014). 10.1021/ja409865c24437942

12.

W. B. Park, Y. S. Jeong, S. P. Singh and K.-S. Sohn, ECS J. Solid State Sci. Technol., 2, R3100 (2012). 10.1149/2.013302jss

13.

K. H. Son, S. P. Singh and K.-S. Sohn, J. Mater. Chem., 22, 8505 (2012). 10.1039/c2jm30280b

14.

W. B. Park, S. P. Singh, C. Yoon and K.-S. Sohn, J. Mater. Chem., 22, 551 (2012). 10.1039/C1JM14416B

15.

A. K. Sharma, C. Kulshreshtha and K.-S. Sohn, Adv. Funct. Mater., 19, 1705 (2009). 10.1002/adfm.200801238

16.

C. Kulshreshtha, A. K. Sharma and K.-S. Sohn, J. Comb. Chem., 10, 421 (2008). 10.1021/cc700198d18341297

17.

Y. S. Jung, C. Kulshreshtha, J. S. Kim, N. Shin and K.- S. Sohn, Chem. Mater., 19, 5309 (2007). 10.1021/cm070976b

18.

K.-S. Sohn, D. H. Park, S. H. Cho, J. S. Kwak and J. S. Kim, Chem. Mater., 18, 1768 (2006). 10.1021/cm052179o

19.

K.-S. Sohn, D. H. Park, S. H. Cho, B. I. Kim and S. I. Woo, J. Comb. Chem., 8, 44 (2006). 10.1021/cc050101z16398552

20.

K.-S. Sohn, J. G. Woo, N. Shin, K. Toda and D. S. Zang, J. Electrochem. Soc., 152, H213 (2005). 10.1149/1.2083208

21.

K.-S. Sohn, J. M. Lee and N. Shin, Adv. Mater., 15, 2081 (2003). 10.1002/adma.200305291

22.

K.-S. Sohn, J. M. Lee, I. W. Jeon and H. D. Park, J. Electrochem. Soc., 150, H182 (2003). 10.1149/1.1591756

23.

C. H. Kim, S. M. Park, J. K. Park, H. D. Park, K.-S. Sohn and J. T. Park, J. Electrochem. Soc., 149, H183 (2002). 10.1149/1.1518992

24.

K.-S. Sohn, I. W. Zeon, H. Chang, S. K. Lee and H. D. Park, Chem. Mater., 14, 2140 (2002). 10.1021/cm0109701

25.

P. Pust, V. Weiler, C. Hecht, A. Tuecks, A. S. Wochnik, A. K. Henss, D. Wiechert, C. Scheu, P. J. Schmidt and W. Schnick, Nat. Mater., 13, 891 (2014). 10.1038/nmat401224952748

26.

W. B. Park, H. Kim, H. Park, C. Yoon and K.-S. Sohn, Inorg. Chem., 55, 2534 (2016). 10.1021/acs.inorgchem.5b0288426901127

27.

S. P. Singh, W. B. Park, C. Yoon, D. Kim and K.-S. Sohn, ECS J. Solid State Sci. Technol., 5, R3032 (2015). 10.1149/2.0041601jss

28.

J. H. Kim. J. W. Park. B. Y. Han, Y. S. Kim and K.-S. Sohn, J. Nanosci. Nanotechnol., 13, 4275 (2013). 10.1166/jnn.2013.702223862486

29.

J. W. Park, B. Y. Han, Y. S. Kim and K.-S. Sohn, J. Nanosci. Nanotechnol., 13, 3955 (2013). 10.1166/jnn.2013.701423862432

30.

W. B. Park, Y. Song, M. Pyo and K.-S. Sohn, Opt. Lett., 38, 1739 (2013). 10.1364/OL.38.00173923938929

31.

W. B. Park, S. P. Singh, C. Yoon and K.-S. Sohn, J. Mater. Chem. C, 1, 1832 (2013). 10.1039/c2tc00731b

32.

W. B. Park. S. P. Singh, M. Pyo and K.-S. Sohn, J. Mater. Chem., 21, 5780 (2011). 10.1039/c0jm03538f

33.

B. Y. Han and K.-S. Sohn, Electrochem. Solid-State Lett., 13, J62 (2010). 10.1149/1.3329742

34.

K.-S. Sohn, J. H. Kwak, Y. S. Jung, H. Yan and M. J. Reece, J. Electrochem. Soc., 155, J58 (2007).

35.

J. Perdew, K. Burke and M. Ernzerhof, Phys. Rev. Lett., 77, 3865 (1996). 10.1103/PhysRevLett.77.386510062328

36.

G. Kresse and J. Hafner, Phys. Rev. B., 47, 558 (1993). 10.1103/PhysRevB.47.55810004490

37.

G. Kresse and J. Hafner, Phys. Rev. B., 49, 14251 (1994). 10.1103/PhysRevB.49.1425110010505

38.

G. Kresse and J. Furthmuller, Comput. Mater. Sci., 6, 15 (1996). 10.1016/0927-0256(96)00008-0

39.

G. Kresse and J. Furthmuller, Phys. Rev. B., 54, 11169 (1996). 10.1103/PhysRevB.54.111699984901

40.

H. J. Monkhorst and J. D. Pack, Phys. Rev. B., 13, 5188 (1976). 10.1103/PhysRevB.13.5188

41.

P. E. Blochl, Phys. Rev. B., 50, 17953 (1994). 10.1103/PhysRevB.50.179539976227

42.

G. Kresse and D. Joubert, Phys. Rev. B., 59, 1758 (1999). 10.1103/PhysRevB.59.1758

43.

B. D. Lee, W. B. Park. J. -W. Lee, M. Kim, M. Pyo and K.-S. Sohn, Chem. Mater., 33, 782 (2021). 10.1021/acs.chemmater.0c04499

Information

Publisher :Materials Research Society of Korea
Publisher(Ko) :한국재료학회
Journal Title :Korean Journal of Materials Research
Journal Title(Ko) :한국재료학회지
Volume : 31
No :4
Pages :188-194
Received Date : 2021-03-08
Revised Date : 2021-03-08
Accepted Date : 2021-03-22
DOI :https://doi.org/10.3740/MRSK.2021.31.4.188
