Reduction of Leakage Current and Enhancement of Dielectric Properties of Rutile-TiO2 Film Deposited by Plasma-Enhanced Atomic Layer Deposition
Su Min Eun1
,
Ji Hyeon Hwang2
,
Byung Joon Choi1†
1Department of Materials Science and Engineering, Seoul National University of Science and Technology, Seoul 01811, Republic of Korea
2Department of Optometry, Seoul National University of Science and Technology, Seoul 01811, Republic of Korea
†Corresponding author E-Mail : bjchoi@seoultech.ac.kr (B. J. Choi, SeoulTech)
27 June 2024. pp. 283-290
PDF XML Citation
Abstract

The aggressive scaling of dynamic random-access memory capacitors has increased the need to maintain high capacitance despite the limited physical thickness of electrodes and dielectrics. This makes it essential to use high-k dielectric materials. TiO2 has a large dielectric constant, ranging from 30~75 in the anatase phase to 90~170 in rutile phase. However, it has significant leakage current due to low energy barriers for electron conduction, which is a critical drawback. Suppressing the leakage current while scaling to achieve an equivalent oxide thickness (EOT) below 0.5 nm is necessary to control the influence of interlayers on capacitor performance. For this, Pt and Ru, with their high work function, can be used instead of a conventional TiN substrate to increase the Schottky barrier height. Additionally, forming rutile-TiO2 on RuO2 with excellent lattice compatibility by epitaxial growth can minimize leakage current. Furthermore, plasma-enhanced atomic layer deposition (PEALD) can be used to deposit a uniform thin film with high density and low defects at low temperatures, to reduce the impact of interfacial reactions on electrical properties at high temperatures. In this study, TiO2 was deposited using PEALD, using substrates of Pt and Ru treated with rapid thermal annealing at 500 and 600 °C, to compare structural, chemical, and electrical characteristics with reference to a TiN substrate. As a result, leakage current was suppressed to around 10-6 A/cm2 at 1 V, and an EOT at the 0.5 nm level was achieved.

Keywords
TiO2
capacitor
leakage current
dielectric constant
plasma-enhanced atomic layer deposition
References
1

W. J. Jeon, J. Mater. Res., 35, 775 (2020).

10.1557/jmr.2019.335
2

S. H. Cha, C. H. An, S. H. Kim, D. G. Kim, D. S. Kwon, S. T. Cho and C. S. Hwang, ECS Meet. Abstr., MA2018-01, 2560 (2018).

10.1149/MA2018-01/44/2560
3

J. J. Chung, S. J. Kim and J. W. Shim, IEEE Trans. Electron Devices, 70, 4315 (2023).

10.1109/TED.2023.3287812
4

W. J. Jeon, S. H. Rha, W. K. Lee, Y. W. Yoo, C. H. An, K. H. Jung, S. K. Kim and C. S. Hwang, ACS Appl. Mater. Interfaces, 6, 7910 (2014).

10.1021/am501247u24749990
5

J. P. Niemela, G. Marin and M. Karppinen, Semicond. Sci. Technol., 32, 093005 (2017).

10.1088/1361-6641/aa78ce
6

B. G. Kim, Y. S. Choi, D. H. Lee, Y. H. Byun, C. W. Jung and H. T. Jeon, ECS J. Solid State Sci. Technol., 10, 083006 (2021).

10.1149/2162-8777/ac1c9c
7

H. J. Kim and I. K. Oh, Jpn. J. Appl. Phys., 53, 03DA01 (2014).

10.7567/JJAP.53.03DA01
8

W. Chiappim, G. E. Testoni, A. C. O. C. Doria, R. S. Pessoa, M. A. Fraga, N. K. A. M. Galvao, K. G. Grigorov, L. Vieira and H. S. Maciel, Nanotechnology, 27, 305701 (2016).

10.1088/0957-4484/27/30/30570127302656
9

N. G. Kubala, P. C. Rowlette and C. A. Wolden, J. Phys. Chem. C, 113, 16307 (2009).

10.1021/jp907266c
10

H. J. Jung, J. H. Han, E. A. Jung, B. K. Park, J. H. Hwang, S. U. Son, C. G. Kim, T. M. Chung and K. S. An, Chem. Mater., 26, 7083 (2014).

10.1021/cm5035485
11

S. K. Kim, W. D. Kim, K. M. Kim, C. S. Hwang and J. H. Jeong, Appl. Phys. Lett., 85, 4112 (2004).

10.1063/1.1812832
12

K. Frohlich, J. Aarik, M. Tapajna, A. Rosova, A. Aidla, E. Dobrocka and K. Huskova, J. Vac. Sci. Technol., B, 27, 266 (2009).

10.1116/1.3021030
13

H. Y. Lee, J. H. Han and B. J. Choi, J. Vac. Sci. Technol., A, 42, 022405 (2024).

10.1116/6.0003319
14

Y. Murakami, J. Li and T. Shimoda, Mater. Lett., 152, 121 (2015).

10.1016/j.matlet.2015.03.084
15

B. Hudec, K.Husekova, A. Rosova, J. Soltys, R. Rammula, A. Kasikov, T. Uustare, M. Micusik, M. Omastova, J. Aarik and K. Frohlich, J. Phys. D: Appl. Phys., 46, 385304 (2013).

10.1088/0022-3727/46/38/385304
16

S. Gupta, M. Sinha, R. Dhawon, R. Jangir, A. Bose, P. Gupta, M. K. Swami and M. H. Modi, Thin Solid Films, 764, 139606 (2023).

10.1016/j.tsf.2022.139606
17

E. V. Jelenkovic and K. Y. Tong, J. Vac. Sci. Technol., B, 22, 2319 (2004).

10.1116/1.1783319
18

J. Aarik, T. Arroval, L. Aarik, R. Rammula, A. Kasikov, H. Mandar, B. Hudec, K. Husekova and K. Frohlich, J. Cryst. Growth, 382, 61 (2013).

10.1016/j.jcrysgro.2013.08.006
19

V. Miikkulainen, M. Leskela, M. Ritala and R. L. Puurunen, J. Appl. Phys., 113, 021301 (2013).

10.1063/1.4757907
20

W. Chiappim, G. E. Testoni, J. S. B. de Lima, H. S. Medeiros, R. S. Pessoa, K. G. Grigorov, L. Vieira and H. S. Maciel, Braz. J. Phys., 46, 56 (2016).

10.1007/s13538-015-0383-2
21

W. Chiappim, M. A. Fraga, H. S. Maciel and R. S. Pessoa, Front. Mech. Eng., 6, 551085 (2020).

10.3389/fmech.2020.551085
22

F. J. Maier, M. Schneider, J. Schrattenholzer and U. Schmid, J. Phys.: Conf. Ser., 1837, 012009 (2021).

10.1088/1742-6596/1837/1/012009
23

P. Soundarrajan, K. Sankarasubramanian, K. Sethuraman and K. Ramamurthi, CrystEngComm, 16, 8756 (2014).

10.1039/C4CE00820K
24

J. Li, H. Cui, Z. Song, N. Wei and J. Tian, Appl. Surf. Sci., 396, 1539 (2017).

10.1016/j.apsusc.2016.11.205
25

P. Lazic and B. N. J. Persson, Europhys. Lett., 91, 46003 (2010).

10.1209/0295-5075/91/46003
26

G. Song, Y. Wang and D. Q. Tan, IET Nanodielectrics, 5, 1 (2022).

10.1049/nde2.12026
27

K. Frohlich, M. Tapajna, A. Rosova, E. Dobrocka, K. Husekova, J. Aarik and A. Aidla, Electrochem. Solid State Lett., 11, G19 (2008).

10.1149/1.2898184
28

W. G. Lee, S. I. Woo, J. C. Kim, S. H. Choi and K. H. Oh, Thin Solid Films, 237, 105 (1994).

10.1016/0040-6090(94)90245-3
29

International Roadmap for Devices and Systems (IRDS) 2023 Edition: Beyond CMOS. Retrieved March 5, 2024 from https://irds.ieee.org/editions/2023

30

K. Frohlich, B. Hudec, M. Tapajna, K. Husekova, A. Rosova, P. Elias, J. Aarik, R. Rammula, A. Kasikov, T. Arroval, L. Aarik, K. Murakami, M. Rommel and A. J. Bauer, ECS Trans., 50, 79 (2013).

10.1149/05013.0079ecst
Information
  • Publisher :Materials Research Society of Korea
  • Publisher(Ko) :한국재료학회
  • Journal Title :Korean Journal of Materials Research
  • Journal Title(Ko) :한국재료학회지
  • Volume : 34
  • No :6
  • Pages :283-290
  • Received Date : 2024-03-11
  • Revised Date : 2024-05-29
  • Accepted Date : 2024-05-29
  • DOI :https://doi.org/10.3740/MRSK.2024.34.6.283
